SERIES 211 – DIFFERENTIAL PRESSURE TRANSMITTER
Applications
- • Building & Duct Static Pressure,
- • Filter Monitoring,
- • Air Flow Measurement,
- • Process Control,
- • Air Handlers,
- • Clean Rooms,
- • Isolation Rooms,
- • Data Centers,
- • Paint Booths,
- • Dust Collectors,
Features
- • Mounts in Industry Standard Holes
- • Accuracy 2%
- • Die Cast Aluminum Housing
- The Series 211 Differential Pressure Transmitter can accurately measure positive, negative, or differential pressure and send the corresponding 4-20 mA output signal. The Series 211 Differential Pressure Transmitter is not position sensitive and can be mounted in any orientation without compromising accuracy. It also features a power LED, so you always know when the transmitter is operating. The compact, lightweight design makes installation simple and easy.
